Acid Resistant Tiles

AvailabilityIn Stock
CategoryAcid Resistant Tiles
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%

Acid Resistant Tiles Details

Chemiprotect Engineers offer high quality acid & alkali resistant unglazed clay tiles (confirming to class-I of IS-4457) for application of acid/alkali resistant lining.

FEATURES & ADVANTAGES

  • CHEMICAL RESISTANCE Resistant to corrosive attack from most Acid/Alkali/Solvents/Chemicals.
  • ABRASION RESISTANCE Resistant to high abrasion even when exposed to high chemical conditions.
  • HIGH TEMPERATURE RESISTANCE
  • THERMAL SHOCK RESISTANCE Can withstand temperature change even under immersion conditions.
  • HIGH IMPACT STRENGTH

FEATURES & ADVANTAGES

  • Chemical Resistant Flooring, Drain & Pit Lining for food, beverages, Dairy, chemical plants.
  • Effluent/Sewerage Treatment Plants
  • Vessels & Tanks Lining
  • Chimney, Flue & FGD Plant
  • Chutes/Hoppers/Tanks/Silos
  • Secondary Containment Area

LIMITATIONS

  • Not suitable if exposed to HF acid, fluoride, fluoride salt solution
  • Not suitable if exposed to strong, hot, high conc. Of Caustic solution
  • Sudden (very rapid) temperature change
ColorOff White
Normal Standard Size230x115, 240x115, 200x100, 150x150, 200x200, 300x300mm
Normal Standard Thickness12, 15 & 20mm
Slip ResistanceExcellent
Standard Coverage Per M238 Pics for 230x115mm size

Different size, thickness and colors available up on special request and for project orders

PHYSICAL PROTERTIES

 Class – 1Class - 2
Bulk Density (Approx.)2.2 to 2.3 g/cc 2.2 to 2.3 g/cc2.2 to 2.3 g/cc 2.2 to 2.3 g/cc
Normal Standard Thickness12, 15 & 20mm
Compressive Strength kg/cm2 Min700500
Water Absorption % Max.24
Flexural Strength kg/cm2 Min10070
Resistance To AcidLoss in wt. shall not exceed 1.5%Loss in wt. shall not exceed 4%

ANALYSIS

SiO270 to 72%
Al2O321 to 24%
Fe2O31.2%
K2) + Na2)2 to 3%
